CENTER ROCK INC.® PRODUCTS
XLP Drill – The Next Evolution in Low-Profile Drilling
XLP Drill™
At Center Rock, innovation is more than a goal — it’s a commitment. Since our breakthrough role in the 2010 Chilean Mine Rescue, where our LP Drill® helped free 33 miners through a 26-inch shaft, we’ve continued pushing drilling technology forward. The new XLP Drill is the latest step in that journey, designed to meet the growing demand for large-diameter, low-headroom drilling with enhanced power, efficiency, and versatility.
Key Features & Innovations
- Lowest Profile, Highest Power: 12 inches shorter than the LP Drill® at 48 inches total overall height for optimal low-headroom performance.
- Lightweight Advantage: 12% lighter for improved handling without sacrificing durability.
- Advanced RX80LP Hammer: High-frequency cycles reduce vibration to the rotary head.
- Integrated Air Selectors: Adjust for maximum productivity or optimize performance with limited air supply.
- Unmatched Strength: RX80LP hammer features a shank with 20–60% more cross-section than competitors.
How the XLP Drill Works
Like all LP Drills®, the XLP houses multiple DTH hammers in a canister, each with a carbide button bit. Compressed air cycles the pistons for rock penetration and clears cuttings from the borehole. Rotation is provided via multiple mounting options, including Kelly Bar or Center Rock’s ratchet attachment.
The XLP supports both conventional circulation (cuttings collected in a calyx basket) and reverse circulation (cuttings removed through a dual-tube drill string).
Specialized LP Drill Variants
For angled underground holes, ventilation, dewatering, and rescue shafts.
Lightweight, air-efficient drilling for utility pole holes in hard rock.
Why Choose the XLP Drill™
The XLP Drill represents Center Rock’s dedication to delivering the most productive and longest-lasting rock drilling tools in the industry. Backed by our expert consultative service and post-sale support, the XLP is available in sizes from 24 to 144 inches in diameter, ready for your toughest projects.
